FlytStat is a command-line based ETL application for anonymized triage data from a Norwegian hospital's ER system. It hashes patient IDs, transforms timestamped records, and graphs patient inflow and symptom distributions.
Built as a final project for the USN PY1010 course.
- Purpose
- Feature Summary
- Installation
- Key Learning Points
- Disclaimer on Scope, Competence and AI
- Project Structure
- License / Usage Disclaimer
The tool aims to serve as an ETL pipeline, extracting a raw datadump from the host software's statistics servers, transform them into a parseable, structured and dynamically accessible format, then load it into a graphical presentation.
FlytStat is run as a CLI tool, and the current version is an MVP, but feature-complete for the scope of the assignment.
🔒 Patient data anonymization
A function that takes a raw data source from the Flyttavle application and hides the marginally identifiable "NPR IDs" with a uniquely indexed alias number. This number is unique to the patient, but stays the same if the patient is admitted again. In this way, one can still compute patient-oriented statistics like total number of visits per patient.
File is opened in binary format, and using the built-in Python "pickle" function, it serializes the ID's into a .pkl / "Pickle" file.
This file, along with the original, un-aliased data source, is excluded from the remote repo through the .gitignore.
- Custom functions
- reading data from file
- Serializing and anonymizing patient data using pickle mapping
- if-statements
- for-loops (counter)
📝 CSV vs. Xlsx
The data source was retrieved from a CSV file. The CSV file alone is around 5 Mb comprised of over 30,000 lines, all in which have over 40 values to them. I quickly found out that parsing a file this big brought many problems; file integrity, parsing, binary stream issues due to memory constraints etc.
In reality, I would likely been able to get around this with research and just a touch of AI assistance (though, the results I tried using both OpenAI and Claude only rendered useless responses despite good prompting), but I made a decision to rather convert this to an .xlsx file - in order to keep the scope of the project within confines.
For a file this large, I would for a production project always have gone with a CSV file (or in reality, a database, even a lightweight one like SQLite) to give better options. I have some experience with SQLite, but as that is outside the scope of PY1010, I chose not to include it.
📊 Plotting
The plots are generated using Matplotlib. Whilst not 100% aesthetically pleasing, they serve their purpose for an MVP.
For a future review, I would consider changing out the model to Seaborn or Plotly.
🐼 Pandas DataFrames
The source data contains roughly 30,000 patient lines, and is the reason why the performance suffers on load. I will consider fixing this in the future, migrating the data into a SQLite or PostgreSQL database.
💻 CLI-based
FlytStat is CLI based, however in a future version I will migrate it to a Django GUI project.
git clone https://github.com/DotWallop/FlytStat.git
cd FlytStatpip install -r requirements.txtI learned a lot of things throughout this project. I have summarized them for myself, and for whomever is reading this.
Follow established best practice!
Stick to best practice. Proactively using DRY, YAGNI and others that I've probably not heard about yet goes a long way.
Think out an OOP structure from the get-go
I started out using a functional structure. As the project grew, I realized how cluttered it had become.
At that point, I did not have time to refactor everything. Depending on when you are grading it, and if I want to take on the task, I might have a separate OOP-branch.
Narrow file scope
Circular import issues, not being able to find the function you want etc... Keep global settings to a global file, import only what you need, where you need it.
Function before looks!
It's super easy to get carried away exploring how to make the program prettier. I spent a bit too much time fiddling around with visual libraries and originally implemented the Rich library with Loguru for pretty-print and rich console output. However this added complexity, And gave errors I did not know how to fix. Thus, I made the decision to remove them. Rookie mistake!
Main guarding is a lifesaver!!
A developer friend of mine taught me about the if __name__ == "__main__" - also called main guarding - function.
This is absolutely crucial for making sure you don't load the whole files from import. Amongst other things I use it to not load the dataframe more than once.
(Hot take) - PEP8 is a cult manual
Ok, maybe not THAT bad 😁, but ... After taking the time to read through the entirety of PEP8, I realize that a lot of it resembles OCD-fueled rambling.
Don't get me wrong, PEP8 is very useful, but it is quite a fun read!
"Know the rules, and know when to break them".
I think it's worth mentioning that I have been honing my Python skills in my free time, expanding from the class scope.
In addition to classes, I have been using Mimo as well as taking several Codecademy courses on Python, Pandas and Matplotlib & NumPy. That is the reason for going slightly outside of scope.
I have utilized ChatGPT and Claude for bugfixing and explanation on specific subjects, including explaining more complex system logic. Nothing has been built purely from AI.
├── main.py # Entry point CLI menu
├── common.py # Global constants and paths
├── data_processing.py # Data loading and transformation
├── metrics.py # Triage and symptom statistics
├── plots.py # Visualization logic
├── plot_styling.py # Centralized plot color styling
├── pages/
│ ├── metadata_page.py # Dataset overview display
│ └── statistics_page.py # Submenu for plotting
├── scripts/
│ └── npr_hashing.py # Patient ID hashing logic
├── data/ # Contains original and hashed data files
├── requirements.txt
└── readme.md
This project is built as a coursework submission. It is not intended for clinical or production use. Patient data is handled securely and fully anonymized (only placeholder numbers are included), but the repository only contains test-safe, hashed output and never stores NPR IDs.
